Ball valve Model GBC-67V

RECEIVER VALVES inlet Connecting =3/8" Male NPT. -outlet Connecting =3/8" Male SAE.FLARE made from hot pressed brass with Teflon (PTFE) valve seat"

Check Valve inlet -outlet Connecting =1/4" Male SAE Flare. made from hot pressed brass with Teflon (PTFE) valve seat Stainless steel spring"

Safety devices 3/8" NPT x 1/2" SAE Model 3060/34

Y- VALVES inlet Connecting = 1/4" Male NPT. -outlet Connecting =1/4" Male SAE. FLARE made from hot pressed brass with Teflon (PTFE) valve seat Stainless steel spring"

Stop valves by diaphragm Diaphragm Valve 3/4"Flare inlet and outlet . Valve use with the following ASHRAE 34:2019 refrigerants, Class A1: HCFC (R22) HFC (R134a, R404A, R407C, R410A, R507) HFO (R1234ze)HFO + HFC (R448A, R449A, R450A, R452A, R513A, R515A, R515B) Connections SAE Flare3/4" Kv [m³/h] 3,65 PS [bar] 28 TS [°C] min. -35 TS [°C] max. +90"

Connections 1-1/8”ODS.(1-3/8"ODM) ,Ts= -35 to +150 C ,Ps=45 bar ,Kv=8.4 m3/h

"Check Valve inlet -outlet Connecting =5/8" ODS. Solder. made from hot pressed brass with Teflon (PTFE) valve seat Stainless steel spring"

วาล์วเปิด-ปิดด้วยมือหมุน  ชนิดขันเกลียวแฟร์ ทางเข้า 3/8" SAE.ทางออก 3/8" SAE"

Connections 2-1/8” ODS.(-"ODM) ,Ts= -35 to +150 C ,Ps=45 bar ,Kv=40.0 m3/h

Flang shut off Valve, Outlet Flare Jointed 3/8"SAE.with in Access Valve Flare 1/4" SAE.

วาล์วเปิด-ปิดด้วยมือหมุน / Stop valves by diaphragm Diaphragm Valve 3/8"ODS Product use with the following ASHRAE 34:2019 refrigerants, Class A1: HCFC (R22) HFC (R134a, R404A, R407C, R410A, R507) HFO (R1234ze)HFO + HFC (R448A, R449A, R450A, R452A, R513A, R515A, R515B) Product Details Connections ODS Ø [in.] 3/8" Kv [m³/h] 1,00 PS [bar] 28 TS [°C] min. -35 TS [°C] max. +90
